Electric Hydraulic Corner Tilter
View Options
Ground Lift Tilter
/ ea.
W X L X H
GLT-4
W X L X H - 63.5" W X 59.25" L X 20.625" H
Uniform Capacity - 4,000 #
Platform W X L X H - 50" X 48" X 1/2"
Lip Height - 17 1/2"
Power - 2 HP, 460/3 Voltage/Phase
Raise/Lower Time Unloaded (sec) - 10/6
-
Product Details
- Includes high lip and removable positioning bar used for smaller containers
- Excellent for tilting applications which require the use of a pallet truck for loading and unloading.
- Rotates containers up to 45 degree from level to provide better access for workers
- Platform Includes 17" high lip on tilt side
- Remote power unit comes with protective cover and hand pendant control
- Pinch point guards are provided on loading side for worker safety
-
Product Videos
Browse All Products
Ground Lift Tilter
Ground Lift Tilter
| PRODUCT ID# | W X L X H | Uniform Capacity | Platform W X L X H | Lip Height | Power | Raise/Lower Time Unloaded (sec) | Price 1-3 | Price 4+ | QTY |
|---|---|---|---|---|---|---|---|---|---|
